KAWASAKI, Japan--(BUSINESS WIRE)-- Toshiba Electronic Devices & Storage Corporation ("Toshiba") has launched four dual-channel, high-speed standard digital isolators for industrial equipment. The new “DCL52xx00 Series†products support stable operation with high common mode transient immunity (CMTI) of 100kV/μs (typ.) and high-speed data rate of 150Mbps (max). Shipments start today.
This press release features multimedia. View the full release here:
Toshiba: DCL52xx00 Series dual-channel digital isolators for industrial equipment.
The channel configuration of "†and “" is two forward channels, while "†and “" have one forward channel and one reverse channel. These new dual-channel products join the previously released quad-channel products in "DCL54xx01 Series" as standard digital isolators for industrial equipment. With the addition of these new products, Toshiba’s overall lineup now covers 14 products, offering a wide selection of channel configurations and helping to improve design flexibility.
The new DCL52xx00 Series products use Toshiba's proprietary magnetic coupling type isolated transmission method to achieve a high CMTI of 100kV/μs (typ.), the same as DCL54xx01 Series products. This delivers high level resistance to electrical noise between input and output in isolated signal transmission, enables stable control signal transmission, and contributes to stable equipment operation.
In addition, a low pulse width distortion of 0.8ns (typ.) and a high-speed data rate of 150Mbps (max) are also achieved. The new products are suitable for multi-channel high-speed communication applications such as I/O interfaces with UART and IC communication.
Toshiba has already started mass production of standard digital isolators for industrial equipment and automotive equipment. Going forward, the company will increase the lineup of packages and number of channels in both areas. It will continue to provide high-quality isolation devices and photocouplers that support the reliability and real-time data transmission required by industrial and automotive equipment.
Notes:
[1]
Test condition: VI=VDDI or 0V, VCM=1500V, Ta=25°°ä (VDDI is VDD1 or VDD2 of the input-side)
[2]
Test condition: VDD1=VDD2=2.25 to 5.5V, Ta=-40 to 125°C
[3]
Test condition: VDD1=VDD2=5V, Ta=25°°ä
[4]
UART (Universal Asynchronous Receiver Transmitter), asynchronous serial communication. Communication method for transmitting and receiving data without a clock signal.
[5]
IC (Inter-Integrated Circuit), synchronous serial communication. Communication method for transmitting and receiving data synchronized with a clock signal.
Applications
Industrial automation systems (programmable logic controllers, I/O interfaces, etc.)
Motor control
Inverters
Features
Dual-channel: Two forward channels; One forward channel and one reverse channel
High common mode transient immunity: CMTI=100kV/μs (typ.)
High-speed data rate: t_bps=150Mbps (max)
Main Specifications
Part number
Number of channels (Forward directions : reverse directions)
2 (2:0)
2 (2:0)
2 (1:1)
2 (1:1)
Default output logic
Low
High
Low
High
Package
SOIC8-N
Absolute maximum ratings
Operating temperature Topr (°°ä)
-40 to 125
Storage temperature Tstg (°°ä)
-65 to 150
Maximum withstanding
isolation voltage (60s)
BVS (Vrms)
Ta=25°°ä
Max
3000
Recommended operating conditions
Power supply voltage
VDD1, VDD2 (V)
Topr=-40 to 125°C
2.25 to 5.5
Electrical characteristics
Common mode
transient immunity
CMTI (kV/μs)
VI=VDDI or 0V,
VCM=1500V,
Ta=25°°ä
Typ.
100
Data rate
t_bps (Mbps)
VDD1=VDD2=2.25 to 5.5V,
Ta=-40 to 125°C
Max
150
Pulse width distortion
PWD (ns)
VDD1=VDD2=5V,
Ta=25°°ä
Typ.
0.8
Propagation delay
tPHL, tPLH (ns)
Typ.
10.9
Sample Check & Availability
Follow the links below for more on the new products.
Follow the link below for more on Toshiba’s standard digital isolators.
To check availability of the new products at online distributors, visit: DCL520C00 DCL520D00 DCL521C00 DCL521D00
